HZS75 StationaryConcrete Batching Plant

Haomei is a hzs75 stationary concrete batching plant factory and supplier with many years of experience. Companies interested in high-quality concrete batching plants and other concrete equipment are welcome to come to consult and quote.

Productivity: 75m3/h
Capacity of Mixer: 1.5m3
Discharge Height: 3.8m
Feeding Type: Skip Hopper

Online Chat Inquiry

Description of HZS75 Concrete Batching Plant

1. The main engine of high quality HZS75 stationary concrete batching plant adopts JS series biaxial forced mixer, which is evenly mixed, with short mixing time, long wearing parts time, convenient operation and maintenance, and adopts control technology. The latest design concept, such as: electric weighing, computer control, digital display, electric weighing is equipped with buffer device and automatic compensation function, high measurement accuracy.

2. The sand conveying system of the mixer adopts flat belt or herringbone belt and is equipped with pavement, which is the ideal choice for the construction company to produce high-quality concrete.

3. The concrete mixing plant is mandatory and efficient equipment, can produce all kinds of concrete including seismic concrete and hard concrete, high production efficiency, widely used in large and medium-sized construction projects, road and bridge engineering. This series of concrete mixing plants are ideal for the production of commercial concrete.

Advantages of HZS75 Concrete Batching Plant

1. The low price hzs75 stationary concrete batching plant not only occupies a small area, but also can be transported.

2. HZS75 concrete mixing plant, suitable for small projects and storage yards.

3. This mixing station has low investment, low noise and is environmentally friendly.

4. The mixing station is easy to install and disassemble.

hzs75 stationary concrete batching plant factory

Differences between forced mixer and self-falling roller mixer

Let hzs75 stationary concrete batching plant supplier talk about this self-falling rolling mixer. It does not have stirring blades. It is mainly the rotation of the entire mixing bucket of the mixer, that is, the blade attached to the mixing bucket brings the material to the air. Fall to the bottom of the mixing bucket, and repeat the cycle, so as to achieve the effect of mixing.

Self-falling drum mixer

1. Rely on the rotation of the mixing bucket to achieve the effect of mixing. There is no mixing fan blade, which is mainly caused by the rotation of the entire mixing bucket of the mixer, that is, the blade attached to the mixing bucket brings the material to the air, and then falls under the mixing bucket by means of a gravity concrete mixing station, so as to cycle repeatedly, so that To achieve the effect of stirring.

2. The mixing bucket of the concrete mixer truck we often see on the construction site or on the road is this way. The mixing of this system usually requires the power of the mixing motor to be small. However, it takes a longer time to stir, and it does less damage to the stirrer.

3. The green roller mixer used on Chinese construction sites is this kind of system, but this system generally has a small host capacity. The most common ones are 0.25, 0.5, 0.75, 1.0, 1.5 cubic meters, and the larger ones are not much Already.

hzs75 stationary concrete batching plant supplier

4. At present, the time for the main unit of this type of mixer to mix homogeneous concrete ranges from 60 to 90 seconds. In terms of this forced mixer, the mixing time is long and the efficiency is relatively low.

Therefore, it is rarely said in China that it is used for large-scale concrete mixing. The sales volume in the small civil construction market is good. It is estimated that the cumulative sales account for about 40% of the total mixer market, but its market price is relatively low , More than 10,000 yuan, so the total amount of sales is not large.

Host system of forced concrete mixing station

1. There are many types of mainframe development for this system. It is estimated that it is in line with China's actual usage habits. It can complete a large amount of concrete production requirements in a short time. Often used are vertical axis planetary mixing, single-horizontal mixing, and double-horizontal Stirring, vertical-shaft vortex-type stirring, and cone-shaped dumping and other stirring forms.

2. But the most commonly used is the double-horizontal axis host, which can be seen in the capacity of 0.5-4 cubic meters, the most common is the range of 1.5-3 cubic meters, this type of dual-horizontal axis hosts accounted for More than 90% is the main share of the market, and the deflected axis planet is used in the production of domestic pipe pile concrete and block concrete. Cone tipping is mostly used for mixing large-diameter hydraulic concrete. Generally, there are few other types of mainframes with a capacity of about 3 cubic meters, and single-shaft ones are also generally used in Germany.

SpecificationUnitValue
Productivitym3/h75

Capacity of Mixer

m31.5

Discharge Height

m3.8

Aggregate Bin

Quantity3

Capacity of Aggregate Bin

m315

Max. Weighing Value of aggregate

kg6000

Max. Weighing Value of cement

kg1000

Max. Weighing Value of water

kg500

Max. Weighing Value of additive

kg50
Feeding Type/Skip Hopper
Cement Silo/Optional
Cement Screw Conveyor/Optional
Control Mode/Auto/Semi control

Production Case



HZS75 Concrete Batching Plant Installed in Philippines

On March 14, 2018, the Halma HZS75 concrete mixing station was successfully installed in the Philippines. Our customers are satisfied with the factory because "it's as good as before".
